Hewlett Packard Enterprise - HPE ProLiant DL380 Gen11 Network Choice

Server - rack-mountable - 2U - 2-way - 1 x Xeon Silver 4410Y / up to 3.9 GHz - RAM 32 GB - SATA - hot-swap 3.5" bay(s) - no HDD - Gigabit Ethernet - no OS - monitor: none - BTO

Hewlett Packard Enterprise
P52562-B21
0190017586199
N/A
New

Price: $9,428.00

MSRP: $9,428.00
In Stock

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HPE ProLiant DL380 Gen11 Network Choice - rack-mountable - Xeon Silver 4410Y 2 GHz - 32 GB - no HDD
Type Server - rack-mountable
Height (Rack Units) 2U
Localization Region: Worldwide
Server Scalability 2-way
Processor 1 x Intel Xeon Silver 4410Y / 2 GHz (, up to 3.9 GHz, (12-core)
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory 30 MB L3 cache
Cache Per Processor 30 MB
RAM 32 GB (installed) / 4 TB (max) - DDR5 SDRAM
Storage Controller SATA (SATA 6Gb/s) (Intel VROC SATA Software RAID)
Server Storage Bays Hot-swap 3.5"
Hard Drive No HDD
Optical Storage No optical drive
Video Memory 16 MB
Networking 1GbE
Power Redundancy Optional
OS Provided No operating system
Software Included HPE Server UEFI
Dimensions (WxDxH) 17.6 in x 28.8 in x 3.4 in
Weight 39.68 lbs
Pricing Type BTO
Environmental Standards ENERGY STAR Qualified
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site - response time: next business day
General
Type Server
Product Form Factor Rack-mountable - 2U
Built-in Devices LED panel
Server Scalability 2-way
Hot-Swap Bays Qty 12
Localization Region: Worldwide
Expansion / Connectivity
Bays 1 (total) / 1 (free) x external Universal Media Bay ¦ 12 (total) / 12 (free) x hot-swap 3.5" LFF
Slots 2 (total) / 2 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode)
Interfaces 1 x USB 3.0 (1 in front) (HPE iLO Service Port) ¦ 4 x USB 3.0 (1 front, 2 rear, 1 internal) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 1 x VGA (1 rear) ¦ 4 x LAN (Gigabit Ethernet) - RJ-45
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Miscellaneous
Included Accessories Cable management arm, HPE standard heatsink, 4 standard fans, SFF Easy Install Rail Kit
Compliant Standards AES, FIPS 140-2, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.3, ErP Lot 9
Pricing Type BTO
RAM
Installed Size 32 GB / 4 TB (max)
Technology DDR5 SDRAM
Effective Memory Speed 4000 MHz
Rated Memory Speed 4800 MHz
Form Factor DIMM 288-pin
Slots 16 (total) / 15 (empty)
Features Registered, dual rank, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only
Configuration Features 1 x 32 GB
Networking
Interface (Bus) Type Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports 4 x Gigabit Ethernet
Ethernet Controller Broadcom BCM5719
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 6
Features Wake on LAN (WoL), PXE support
Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 100-240 V
Power Provided 800 Watt
80 PLUS Certification 80 PLUS Platinum
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% RH (non-condensing)
Storage Controller
Type 1 x SATA
Controller Interface Type SATA 6Gb/s
Storage Controller Name Intel VROC SATA Software RAID
Channel Qty 14
RAID Level RAID 0, RAID 1, RAID 5, RAID 10
Cache Memory
Installed Size L3 cache - 30 MB
Cache Per Processor 30 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Video Memory 16 MB
Video Interfaces VGA
Operating System / Software
OS Provided No operating system
OS Certified Microsoft Windows Server, Red Hat Enterprise Linux, VMware ESXi, Oracle Linux, Canonical Ubuntu, Citrix
Software HPE Server UEFI
Hard Drive
Type No HDD
Dimensions & Weight
Width 17.6 in
Depth 28.8 in
Height 3.4 in
Weight 39.68 lbs
Processor / Chipset
CPU Intel Xeon Silver 4410Y
Clock Speed 2 GHz
Max Turbo Speed 3.9 GHz
Number of Cores 12-core
CPU Qty 1
Max CPU Qty 2
CPU Upgradability Upgradable
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
Chipset Type Intel C741
Sustainability Information
ENERGY STAR Certified Yes
ENERGY STAR Version 3.0
