Hewlett Packard Enterprise - HPE R1500 G5
UPS (rack-mountable) - AC 100/120-125 V - 1920 Watt - 1920 VA - 1-phase - RS-232, USB - output connectors: 5 - 1U - North America
Product Description
What's Included
| Main Specifications | |
|---|---|
| Product Description | HPE R1500 G5 - UPS - 1920 watt - 1920 VA |
| Device Type | UPS - rack-mountable |
| Rack Size | 1U |
| Weight | 43.47 lbs |
| Localization | North America |
| Input Wiring | 1-phase |
| Input Voltage | AC 100/120-125 V |
| Power Capacity | 1920 watt / 1920 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 5 x power NEMA 5-15R |
| Battery | Lead acid |
| Run Time (Up To) | 5 min at full load |
| Networking | RS-232, USB |
| Included Accessories | Rack mounting rails |
| Dimensions (WxDxH) | 17.2 in x 21.8 in x 1.7 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable |
| Height (Rack Units) | 1U |
| Localization | North America |
| Expansion / Connectivity | |
| Interfaces | 1 x USB ¦ 1 x RS-232 - 9 pin D-Sub (DB-9) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 1 year ¦ Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Rack mounting rails |
| Cables Included | USB cable ¦ Serial cable ¦ Power cable - integrated |
| Rack Mounting Kit | Included |
| Equipment Protection Value | 250000 US Dollars |
| Features | VRLA battery support, LCD display |
| Compliant Standards | UL, cUL, TUV, C-Tick, EAC, VCCI Class B, GS, KC, EK, BSMI, BIS, UL 1778, UL 60950, CSA 22.2, CB, IEC 62040-1, IEC 60950-1, EN 60950-1, EN 62040-1, EN 61000-3-2, EN 61000-3-3, CISPR 22, FCC CFR47 Part 15, EN 50091-2, EN55024, IEC 61000-4-2, IEC 61000-4-6, IEC 61000-4-11, ANSI C62.41 |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Software / System Requirements | |
| Software Included | HP Power Protector (free download) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Sound Emission | 45 dBA |
| Battery | |
| Technology | Lead acid |
| Voltage Provided | 36 V |
| Run Time (Up To) | 39 min at 20% load ¦ 12 min at half load ¦ 7 min at 80% load ¦ 5 min at full load |
| Recharge Time | 24 hours |
| Features | Maintenance free, sealed |
| Power Device | |
| UPS Technology | Line interactive |
| Input Voltage | AC 100/120-125 V |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 5 x power NEMA 5-15R |
| Power Capacity | 1920 watt / 1920 VA |
| Output Waveform | Sinewave |
| Efficiency | 92% |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 21.8 in |
| Height | 1.7 in |
| Weight | 43.47 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 22.8 in |
| Shipping Depth | 30.7 in |
| Shipping Height | 6.1 in |
| Shipping Weight | 54.45 lbs |
